57105 Murr Elektronik I/O Systems

Product Details

• Weight
  160 g
• Series
  Field Bus System
• Dimensions H×W×D
  109×48.5×76.5 mm
• Diagnostic via BUS
  per module
• Operating voltage
  24 V DC (EN 61131-2)
• Output current (I/Os /Backplane)
  10 A/3 A
• Output voltage (I/Os /Backplane)
  24 V DC/5 V DC
• Actuator warning
  no
• Sensor-system/actuator supply
  4× spring clamp plug-in terminals, max. 1.5 mm² (max. 10 A)
• Fieldbus
  Ethernet 10/100 Mbit/s; 1× RJ45 (female)
• Internal system connection
  4× spring clamp plug-in terminals, max. 1.5 mm² (max. 10 A)
• Connection
  Spring clamp plug-in terminals: max. 1.5 mm² (max. 10 A)
• Addressing
  DHCP, BOOTP or IP address by rotary switch
• Short-circuit and overload
  yes
• Diagnostic via LED
  per module and channel
• Protection
  IP20
• Module capacity
  max. 64
• Monitoring - no voltage
  yes
• Mounting method
  DIN-rail mountable (EN 60715)
• Communication status
  via LED
Temperature range
0...+60 °C (storage temperature -25...+70 °C)
I/O capacity
max. 1 024 Byte (Input), max. 1 024 Byte (Output)
Monitoring - under voltage
no
Current consumption
max. 95 mA
Product article number of manufacturer
57105
