56640 Murr Elektronik I/O Systems

Product Details

• Weight
  210 g
• Series
  Field Bus System
• Mounting method
  2-hole screw mounting
• Current consumption
  max. 50 mA
• Diagnostic via LED
  per module and channel
• Protection
  IP67
• LED display
  US: sensor supply and internal supply voltage (green: OK); UA: actuator supply (green: OK)
• Diagnostic via BUS
  per module and channel
• Sensor supply US
  24 V DC (EN 61131-2), max. 200 mA (M12 female), short-circuit and overload protected
• I/O ports
  M12 (female) 5-pole, A-coded
• Actuator warning
  per channel via LED and BUS
• Dimensions H×W×D
  126×50×34.5 mm
• PIN 2
  Input/Output/Diagnostic
• Monitoring - under voltage
  yes
• Actuator supply UA
  24 V DC (EN 61131-2), via system connection (max. 4 A) + right actuators via supply right (max. 4 A)
• PIN 4
  Input/Output
• Type
  for 3-wire sensors or mechanical switches, PNP
• Product article number of manufacturer
  56640
• Switching current per output
  max. 1.6 A (short-circuit and overload protected)
• Fieldbus
  via internal system connection
Monitoring - no voltage
yes
Lamp load
30 W
Sensor-system/actuator supply
via internal system connection (max. 2× 4 A)
Short-circuit and overload
yes
Input filter
1 ms
Communication status
via LED
Temperature range
0...+55 °C (storage temperature -20...+75 °C)
Terminating resistor
integrated into the module
