27032 Murr Elektronik I/O Distributors

Product Details

• Weight
  1121 g
• Series
  Distribution Systems
• Dimensions H×W×D
  125×50.2×17 mm
• Material (jacket)
  PUR/PVC
• Material
  PBT
• Cable number
  388
• Product article number of manufacturer
  27032
• Housing
  Plastic, flame retardant
• Wire isolation
  PVC (yebr, rd, grpk, wh, rdbl, gn, whgn, ye, brgn, gr, whye, pk, br, gnye, bl)
• Temperature range (fixed)
  -30...+80 °C
• No./diameter of wires
  12× 0.34 + 3× 0.75 mm²
• Color (jacket)
  gray
• Protection
  IP65 and IP67 when plugged and screwed down (EN 60529)
• Bend radius (fixed)
  10× outer Ø
• Operating current per contact
  max. 4 A
• Temperature range (mobile)
  -5...+70 °C
• Total current
  max. 8 A
• Outer Ø
  9.8 mm ±5%
• Temperature range
  -20...+80 °C
• Jacket Color
  gray
Signal per port
2
Bend radius (moving)
12× outer Ø
Operating voltage
24 V DC ±25%
C-track properties
2 Mio.
