G12C0000

Red Lion

Red Lion G12C0000 is an HMI operator touchscreen panel from the HMI Rugged Graphite series designed for indoor use. It features a connection interface that includes 1 x RJ45 port for Ethernet connectivity, 2 x RJ11 ports supporting RS-232 communication, and an additional RJ45 port for RS-422 / RS-485 communication protocols. The unit operates on a supply voltage range of 10-30Vdc, accommodating both 12Vdc and 24Vdc systems. It is engineered to function within an ambient air temperature range of -20 to +60 °C and boasts a degree of protection rated at IP66 and NEMA 4X. The G12C0000 offers connection capacity with 8 x module slots and has a power consumption profile of typically 16 W, with a maximum of 56 W. Its electrical durability is highlighted by a backlight lifespan of 70,000 hours. For data storage, it is equipped with an SD card slot. The display's brightness is rated at 400cd/m2, ensuring clear visibility under various lighting conditions.
