AMU2060NLF Allied Moulded Products Electrical Enclosures

Product Details

• UL Standard
  508A
• UL CCN
  NITW
• UL File No.
  E120175
• Width
  16.09 in
• Height
  19.87 in
• Depth
  9.95 in
• NEMA Rating
  4X
• Material
  Fiberglass
• Color
  Gray
• Type
  Wallmount
• Door Qty
  1
• Usable Depth:
  10.09 in
• Closure Type:
  Nonmetal Snap Latch
• Patents:
  U.S. Patent No. 7,572,975
• Width:
  16.09 in
• Country of Origin:
  United States of America
• Volume:
  3517 cu. in.
• Brand:
  ULTRALINE®
• Features:
  Non-corrosive, non-conductive, light weight with lower installation cost, easy to modify and longer life cycle compared to steel. Rigid design with back panel inserts plus nonmetallic mounting brackets and a gasket system encased in a continuous channel o
• Cover Type:
  Opaque
UPC:
85339998327
Depth:
9.95 in
Color:
Gray (RAL 7035)
Enclosure Type:
JIC Size
Carton Quantity:
1
Height:
19.87 in
Carton Weight:
18 lbs
Mounting Description:
Nonmetal flange fastened to back side brass inserts
UNSPSC:
39121324
Additional Materials:
316 stainless steel external hardware (hinges/latches/fasteners), Polycarbonate mounting brackets, Plated carbon steel internal hardware, Brass inserts, Polyurethane (FIP) Formed-In-Place gasket system
Standards:
UL 508A, UL 50 and UL 50E Types 1, 2, 3, 3R, 4, 4X, 12 and 13; File No. E120175Complies with: 1. EN / IEC 60204-1 and 60529 Type IP66 2. RoHS directive
Application:
Enclose and protect electrial and electronic controls, instruments or components for indoor and outdoor applications. Especially well suited for extreme temperature and corrosive environments.
Material:
ULTRAGUARD® Fiberglass reinforced polyester - compression molded SMC box and Cover
