AM864HP6 Allied Moulded Products Pushbutton Enclosures

Product Details

• UL Standard
  508A
• UL CCN
  NITW
• UL File No.
  E120175
• Width
  6.13 in
• Height
  8 in
• Depth
  4.01 in
• NEMA Rating
  4X
• Material
  Fiberglass
• Color
  Gray
• Type
  Wallmount
• Door Qty
  1
• Closure Type:
  2-Screw
• Standards:
  UL 508A, UL 50 and UL 50E Types 1, 2, 3, 3R, 4, 4X, 12 and 13; File No. E120175Complies with: 1. EN / IEC 60204-1 and 60529 Type IP66 2. RoHS directive
• Usable Depth:
  3.71 in
• Height:
  8 in
• Mounting Description:
  Stainless steel feet fastened to back side brass inserts
• Brand:
  AM Series
• Depth:
  4.01 in
• UNSPSC:
  39121326
• Width:
  6.13 in
Cover Type:
Opaque
Volume:
203 cu. in.
Material:
ULTRAGUARD® Fiberglass reinforced polyester - compression molded SMC box and Cover
Enclosure Type:
Pushbutton
Color:
Gray (RAL 7035)
UPC:
85339908753
Carton Weight:
4 lbs
Carton Quantity:
1
Country of Origin:
United States of America
Features:
Non-corrosive, non-conductive, light weight with lower installation cost, easy to modify and longer life cycle compared to steel. Rigid design with back panel inserts plus stainless steel mounting brackets and a gasket system encased in a continuous chann
Additional Materials:
316 stainless steel external hardware (hinges/latches/fasteners), 316 stainless steel mounting brackets, Plated carbon steel internal hardware, Brass inserts, Polyurethane (FIP) Formed-In-Place gasket system
Application:
Designed to protect push-button switches from damage and wear, these enclosures have holes for mounting push buttons and an internal compartment to house associated wires and mechanisms. Push buttons are often used for operating industrial machines or pro
