AM1868HP42 Allied Moulded Products Pushbutton Enclosures

Product Details

• UL Standard
  508A
• UL CCN
  NITW
• UL File No.
  E120175
• Width
  16.4 in
• Height
  18.4 in
• Depth
  8.01 in
• NEMA Rating
  4X
• Material
  Fiberglass
• Color
  Gray
• Type
  Wallmount
• Door Qty
  1
• Standards:
  UL 508A, UL 50 and UL 50E Types 1, 2, 3, 3R, 4, 4X, 12 and 13; File No. E120175Complies with: 1. EN / IEC 60204-1 and 60529 Type IP66 2. RoHS directive
• Width:
  16.4 in
• UNSPSC:
  39121326
• Depth:
  8.01 in
• Color:
  Gray (RAL 7035)
• Cover Type:
  Opaque
• Carton Weight:
  17 lbs
• Enclosure Type:
  Pushbutton
• Volume:
  2453 cu. in.
UPC:
85339918790
Usable Depth:
7.69 in
Carton Quantity:
1
Mounting Description:
Stainless steel feet fastened to back side brass inserts
Additional Materials:
316 stainless steel external hardware (hinges/latches/fasteners), 316 stainless steel mounting brackets, Plated carbon steel internal hardware, Brass inserts, Polyurethane (FIP) Formed-In-Place gasket system
Closure Type:
2-Screw
Material:
ULTRAGUARD® Fiberglass reinforced polyester - compression molded SMC box and Cover
Height:
18.4 in
Country of Origin:
United States of America
Brand:
AM Series
Features:
Non-corrosive, non-conductive, light weight with lower installation cost, easy to modify and longer life cycle compared to steel. Rigid design with back panel inserts plus stainless steel mounting brackets and a gasket system encased in a continuous chann
Application:
Designed to protect push-button switches from damage and wear, these enclosures have holes for mounting push buttons and an internal compartment to house associated wires and mechanisms. Push buttons are often used for operating industrial machines or pro
